24V 150AH RV Batteries

Product Overview

The 24V 150Ah RV battery is a 25.6V lithium iron phosphate energy module designed for RV distributors, camper manufacturers, and system integrators across North America, Australia, and Europe. With a nominal energy of 3840Wh, it supports medium to large recreational vehicles requiring reliable off-grid autonomy.

Compared with traditional lead-acid systems, this RV lithium battery reduces weight while increasing usable capacity. The battery weighs only 25 kg, significantly lighter than comparable deep cycle RV battery alternatives, improving vehicle payload efficiency.

Engineered for mobile power integration, the unit supports inverter systems, solar charging controllers, and onboard appliance loads including RV air conditioning systems.

Key Features & Benefits

1. High Energy Density Lithium Architecture

Built using LiFePO4 cells, the 24V 150Ah RV battery offers higher energy density than lead-acid configurations. With 3840Wh of usable power, it supports extended off-grid camping durations.

2. Ultra-Long Cycle Life

The battery exceeds 6000 cycles at 80% depth of discharge. For RV fleet operators and rental businesses, this significantly lowers total cost of ownership compared to conventional RV house battery systems.

3. Stable Voltage Output

A consistent 25.6V nominal output ensures sensitive electronics, refrigerators, and inverter-driven compressors operate without brownouts. This stability is critical for modern camper battery lithium upgrades.

4. Smart BMS Integration

Equipped with JBD BMS or JK BMS, the system supports:

• CAN communication

• RS485

• Modbus protocol

• Active balancing

These features enable integration into advanced RV energy storage system architectures.

5. IP65 & Vibration Resistance

Designed for mobile environments, the metal casing provides IP65 protection against dust and water spray. Internal resistance ≤10 mΩ ensures efficient power transfer even under dynamic load conditions.

Technical Specifications

Operating temperature range supports:

• Charge: 0°C to 60°C

• Discharge: -20°C to 65°C

Self-discharge remains ≤2% per month, supporting long-term storage scenarios.

Applications

The 24V 150Ah RV battery is engineered for:

• Class B and Class C motorhomes

• Camper van conversions

• Off-grid RV systems

• Solar RV installations

• Mobile energy storage platforms

• RV air conditioning systems

• Onboard cooking appliances

• Remote work mobile offices

When deployed as a deep cycle RV battery, it supports extended inverter operation without significant voltage drop. Solar integrators can pair the battery with MPPT controllers to form a complete RV energy storage system.

Comparison / Advantages

Unlike conventional deep cycle RV battery options, this lithium platform eliminates sulfation risk and watering maintenance.

---

Certifications & Quality Standards

The battery is manufactured under strict quality management aligned with international standards such as ISO 9001 (external link)
https://www.iso.org/iso-9001-quality-management.html

Cells comply with global lithium safety transport regulations and are suitable for export to USA, Canada, Australia, and Europe.

Each 24V 150Ah RV battery undergoes performance testing including capacity verification, internal resistance measurement, and BMS functional validation before shipment.

OEM & Customization

Full OEM and ODM services are supported:

• Custom branding

• Casing color modification

• Firmware configuration

• CAN protocol adaptation

• LCD display integration

• Bluetooth & APP monitoring

• WiFi or 4G connectivity

• GPS tracking

• Self-heating module

• Circuit breaker addition

For camper manufacturers building proprietary RV house battery solutions, protocol-level customization ensures seamless integration.

Maximum configuration supports:

• 4 batteries in series

• 4 batteries in parallel

This scalability allows energy expansion beyond 15kWh.

CTA

For RV distributors, camper manufacturers, and solar system integrators seeking a scalable lithium solution, the 24V 150Ah RV battery provides reliable, long-life energy storage engineered for demanding mobile applications. Contact our engineering team to discuss OEM integration.
